Carlisle Plume Plotter
Carlisle incinerator plume
at 16:20 on Fri, 09 Dec 2022
MAIN
PLACES
PLEASE WAIT...
map
Map
MAIN
PLACES

The map shows the (predicted) current state of pollution from the proposed incinerator at Kingmoor Park Industrial Estate.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 8.73 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOCs
Hydrogen flouride
Ammonia
Cadmium and Thallium
Mercury
Other metals
PAHs
Dioxins and furans
PCBs

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOCs
Hydrogen flouride
Ammonia
Cadmium and Thallium
Mercury
Other metals
PAHs
Dioxins and furans
PCBs

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen13.5 µg8.73 µg(65%)
Sulphur dioxide2.98 µg2.18 µg(73%)
Carbon monoxide252 µg3.64 µg(1%)
Particulates11.7 µg364 ng(3%)
Hydrogen chloride710 ng437 ng(61%)
VOCs860 ng728 ng(85%)
Hydrogen flouride2.35 µg72.8 ng(3%)
Ammonia4.23 µg728 ng(17%)
Cadmium and Thallium38 pg1.46 ng(3829%)
Mercury1.51 ng1.46 ng(96%)
Other metals7.38 ng21.8 ng(296%)
PAHs160 pg7.65 pg(5%)
Dioxins and furans33 fg4.37 fg(13%)
PCBs127 pg364 pg(285%)
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 6.9 mph (3.1 m/s) from 260°. Cloud cover: 0/10. Temp: -3°C. Pressure: 1004 mb. Data from Spadeadam airport at 16:20.
