The map shows the (predicted) current state of pollution from the proposed incinerator at Generation Park.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 132 ng/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Sulphur dioxide
Particulates
Carbon monoxide
Hydrogen chloride
Ammonia

Oxides of nitrogen
Sulphur dioxide
Particulates
Carbon monoxide
Hydrogen chloride
Ammonia

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen22.8 µg132 ng(1%)
Sulphur dioxide6.63 µg132 ng(2%)
Particulates20.4 µg13.2 ng(0%)
Carbon monoxide458 µg247 ng(0%)
Hydrogen chloride490 ng19.8 ng(4%)
Ammonia1.92 µg9.88 ng(1%)
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 5.8 mph (2.6 m/s) from 90°. Cloud cover: 1/10. Temp: 16°C. Pressure: 1029 mb. Data from Norwich Weather Centre airport at 21:50.
