Portland Plume Plotter
Portland incinerator plume
at 15:20 on Sat, 23 Sep 2023
MAIN
PLACES
PLEASE WAIT...
map
Map
MAIN
PLACES

The map shows the (predicted) current state of pollution from the proposed incinerator at Balaclava Bay.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 3.91 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOCs
Hydrogen flouride
Ammonia
Cadmium and Thallium
Mercury
Other metals
PAHs
Dioxins and furans
PCBs

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOCs
Hydrogen flouride
Ammonia
Cadmium and Thallium
Mercury
Other metals
PAHs
Dioxins and furans
PCBs

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen22 µg3.91 µg(18%)
Sulphur dioxide3.32 µg976 ng(29%)
Carbon monoxide209 µg1.63 µg(1%)
Particulates14.7 µg162 ng(1%)
Hydrogen chloride710 ng195 ng(27%)
VOCs270 ng326 ng(121%)
Hydrogen flouride2.35 µg32.5 ng(1%)
Ammonia820 ng326 ng(40%)
Cadmium and Thallium570 pg651 pg(114%)
Mercury2.8 ng651 pg(23%)
Other metals124 ng9.77 ng(8%)
PAHs980 pg3.42 pg(0%)
Dioxins and furans33 fg1.95 fg(6%)
PCBs129 pg3.42 pg(3%)
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 9.2 mph (4.1 m/s) from 230°. Cloud cover: 4/10. Temp: 17°C. Pressure: 1018 mb. Data from Bournemouth airport at 15:20.
