The map shows the (predicted) current state of pollution from the proposed incinerator at Rivenhall.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 73 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOCs
Hydrogen flouride
Ammonia
Cadmium and thallium
Mercury
Other metals
Benzo(a)pyrene
Dioxins and furans
PCBs

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOCs
Hydrogen flouride
Ammonia
Cadmium and thallium
Mercury
Other metals
Benzo(a)pyrene
Dioxins and furans
PCBs

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen18.6 µg73 µg(392%)
Sulphur dioxide6.2 µg36.5 µg(589%)
Carbon monoxide301 µg36.5 µg(12%)
Particulates20.2 µg7.3 µg(36%)
Hydrogen chloride720 ng7.3 µg(1014%)
VOCs600 ng7.3 µg(1217%)
Hydrogen flouride2.35 µg736 ng(31%)
Ammonia1.8 µg7.3 µg(406%)
Cadmium and thallium150 pg14.6 ng(9729%)
Mercury1.51 ng36.5 ng(2417%)
Other metals16.5 ng365 ng(2210%)
Benzo(a)pyrene140 pg76.6 pg(55%)
Dioxins and furans22.8 fg73 fg(320%)
PCBs142 pg3.65 ng(2581%)
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 21.9 mph (9.8 m/s) from 170°. Cloud cover: 8/10. Temp: 10°C. Pressure: 978 mb. Data from Stansted airport at 15:50.
