The map shows the (predicted) current state of pollution from the incinerator at Bernard Road.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 4.3 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Particulates
Sulphur dioxide
VOCs
Carbon monoxide
Cadmium and thallium
Other metals

Oxides of nitrogen
Particulates
Sulphur dioxide
VOCs
Carbon monoxide
Cadmium and thallium
Other metals

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen27.6 µg4.3 µg(16%)
Particulates13.9 µg62.4 ng(0%)
Sulphur dioxide2.94 µg485 ng(16%)
VOCs842 ng0(0%)
Carbon monoxide237 µg144 ng(0%)
Hydrogen chlorideN/A242 ng
Hydrogen flourideN/A3.57 ng
AmmoniaN/A0
Cadmium and thallium445 pg33.1 pg(7%)
MercuryN/A78.1 pg
Other metals111 ng567 pg(1%)
Dioxins and furansN/A0.225 fg
PAHsN/A8.37 pg
PCBsN/A0.0376 fg
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Historical
Latest weather data
Wind 8.1 mph (3.6 m/s) from 320°. Cloud cover: 0/10. Temp: 20°C. Pressure: 1029 mb. Data from Doncaster Sheffield airport at 22:20.
