Shepperton Gasifier Plume Plotter
Shepperton Gasifier (only) plume
at 20:50 on Sun, 25 Feb 2024
MAIN
PLACES
PLEASE WAIT...
map
Map
MAIN
PLACES

The map shows the (predicted) current state of pollution from the proposed (only) at Charlton Lane.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 2.59 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Sulphur dioxide
Particulates
Carbon monoxide
Hydrogen chloride
Hydrogen flouride
TOC
Ammonia
Cadmium and thallium
Mercury
Other metals
Benzo(a)pyrene
Dioxins and furans
PCBs

Oxides of nitrogen
Sulphur dioxide
Particulates
Carbon monoxide
Hydrogen chloride
Hydrogen flouride
TOC
Ammonia
Cadmium and thallium
Mercury
Other metals
Benzo(a)pyrene
Dioxins and furans
PCBs

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen37.6 µg2.59 µg(7%)
Sulphur dioxide4.39 µg1.29 µg(29%)
Particulates24.1 µg259 ng(1%)
Carbon monoxide470 µg1.29 µg(0%)
Hydrogen chloride530 ng259 ng(49%)
Hydrogen flouride2.35 µg25.9 ng(1%)
TOC1.07 µg259 ng(24%)
Ammonia1.48 µg259 ng(17%)
Cadmium and thallium220 pg1.29 ng(589%)
Mercury2.02 ng1.29 ng(64%)
Other metals26 ng12.9 ng(50%)
Benzo(a)pyrene190 pg2.59 pg(1%)
Dioxins and furans27.8 fg2.59 fg(9%)
PCBs243 pg129 pg(53%)
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 13.9 mph (6.2 m/s) from 60°. Cloud cover: 10/10. Temp: 6°C. Pressure: 994 mb. Data from London Heathrow airport at 20:50.
