Swansea Plume Plotter
Swansea incinerator plume
at 22:20 on Mon, 08 Aug 2022
MAIN
PLACES
PLEASE WAIT...
map
Map
MAIN
PLACES

The map shows the (predicted) current state of pollution from the proposed incinerator at Clarion Close, Morriston.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 27.5 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Particulates
Sulphur dioxide
Carbon monoxide
Hydrogen chloride
VOCs
Cadmium and thallium
Mercury
Other metals
PAHs

Oxides of nitrogen
Particulates
Sulphur dioxide
Carbon monoxide
Hydrogen chloride
VOCs
Cadmium and thallium
Mercury
Other metals
PAHs

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen12.6 µg27.5 µg(217%)
Particulates12.7 µg1.37 µg(11%)
Sulphur dioxide3.33 µg6.87 µg(206%)
Carbon monoxide112 µg6.87 µg(6%)
Hydrogen chloride 212 ng1.37 µg(644%)
Hydrogen fluoride N/A137 ng
VOCs450 ng1.37 µg(304%)
Cadmium and thallium320 pg6.93 ng(2165%)
Mercury3.5 ng6.93 ng(198%)
Other metals71 ng68.7 ng(97%)
Dioxins and furansN/A13.7 fg
PAHs400 pg2.37 pg(1%)
PCBsN/A1.26 fg
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 8.1 mph (3.6 m/s) from 320°. Cloud cover: 0/10. Temp: 18°C. Pressure: 1027 mb. Data from Cardiff airport at 22:20.
