Waterbeach Plume Plotter
Waterbeach incinerator plume
at 20:56 on Mon, 08 Aug 2022
MAIN
PLACES
PLEASE WAIT...
map
Map
MAIN
PLACES

The map shows the (predicted) current state of pollution from the proposed incinerator at Waterbeach, Cambridge.

The red line shows wind direction. Green rings show distance (km). Colours show concentration of oxides of nitrogen at ground level. Maximum: 6.58 µg/m3. This is the concentration at the location that is most polluted by the plume.

Breakdown of pollutants at most polluted location (green = background, red = added by plume):

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOC
Hydrogen flouride
Ammonia
Mercury
Cadmium and thallium
Other metals
Dioxins and furans
Benzo(a)pyrene
PCBs

Oxides of nitrogen
Sulphur dioxide
Carbon monoxide
Particulates
Hydrogen chloride
VOC
Hydrogen flouride
Ammonia
Mercury
Cadmium and thallium
Other metals
Dioxins and furans
Benzo(a)pyrene
PCBs

Concentration
per m3
Background
(annual mean)
Plume
Oxides of nitrogen15.1 µg6.58 µg(44%)
Sulphur dioxide8.67 µg1.64 µg(19%)
Carbon monoxide315 µg1.64 µg(1%)
Particulates18.4 µg329 ng(2%)
Hydrogen chloride710 ng329 ng(46%)
VOC400 ng329 ng(82%)
Hydrogen flouride2.35 µg32.9 ng(1%)
Ammonia2.9 µg329 ng(11%)
Mercury2.43 ng1.64 ng(68%)
Cadmium and thallium300 pg1.64 ng(548%)
Other metals30.1 ng16.4 ng(55%)
Dioxins and furans33 fg3.29 fg(10%)
Benzo(a)pyrene140 pg6.9 pg(5%)
PCBs127 pg164 pg(129%)
Display parameters
Zoom:
+
Area:
Centred
Downwind
Emissions:
Planned
Latest weather data
Wind 8.1 mph (3.6 m/s) from 90°. Cloud cover: 0/10. Temp: 21°C. Pressure: 1027 mb. Data from RAF Lakenheath airport at 20:56.
